YCM® Compatible Modular Subplates

Description

YCM STATES: “YCM (Yeong Chin Machinery Industries Co. Ltd.) specializes in machine tool manufacturing”

YCM builds many CNC mills — and we’re proud to offer Tosa Tool modular fixturing that fits them.

Modular fixture plates for YCM CNC mills, made to order in Wisconsin, USA. Pick your machine series and model below for an OEM-fit envelope with the standard Tosa Tool (TT) hole pattern — two nestled 1.250″ grids (precision Ø.5010″ bores + 1/2-13 threaded holes with counterbore).

Materials: PH 4140 PreHard steel · MC medium-carbon steel · AL 7075-T6 aluminum.

Select your plate, then Add Options to your Modular Subplate and add built-to-fit hardware accessories.

Don’t see your mill, or need a custom size? Use the Custom Plate Builder or call 608-721-TOOL / dan@tosatool.com.

YCM compatible modular subplates

Tosa Tool builds OEM-fit modular fixture plates for YCM CNC mills and machining centers. Plates are designed around your machine table for modular workholding without re-tramming.

Machine series & models

Current YCM options include NXV, NMV, NSV and more. Use the dropdowns above to select series, model, and material.

Tosa Tool hole pattern (TT)

Two nestled 1.2500″ grids provide precision Ø.5010″ locating bores and 1/2-13 threaded holes with counterbores.

Material options

• PH — 4140 PreHard steel
• MC — medium-carbon steel
• AL — 7075-T6 aluminum

Made to order in Wisconsin. Complete the setup with modular vise, angle plates, and clamping kits.
