DN SOLUTIONS® (formerly Doosan) Compatible Modular Subplates

Description

DN Solutions (formerly Doosan) compatible modular subplates

Tosa Tool builds OEM-fit modular fixture plates for DN Solutions (formerly Doosan) vertical machining centers — DNM, DEM, BVM, SVM, MYNX, VM and VX, plus the VC twin-pallet and XC 2-spindle machines. These plates are designed around your machine’s table so you can mount once and change setups with modular workholding — without re-tramming a vise every job.

A salute to DN Solutions

DN SOLUTIONS STATES: “Machine Greatness has two meanings around here. The first is simple: DN Solutions builds great machines. The second meaning is your call to action: Use your DN Solutions machine to make great things.”

Doosan Machine Tools became DN Solutions in 2022 — same Korean-built machines, same model names. If you run a Doosan DNM, MYNX, VC or BVM, your plate is listed here.

We’re proud to offer modular plates designed to fit these machines exactly.

Machine series & models in the configurator

Use the dropdowns above to select series → model → material. Current DN Solutions / Doosan options include:

• BVM series: BVM5700
• DEM series: DEM4000
• DNM series: DNM4000, DNM4500, DNM4500L, DNM4500S, DNM5700, DNM5700L, DNM5700S, DNM650P (discontinued), DNM650/50II, DNM6700, DNM6700L, DNM6700XL, DNM750II, DNM750LII, DNM750/50II
• MYNX series: MYNX5400II, MYNX5400/50II, MYNX6500II, MYNX6500/50II, MYNX7500II, MYNX7500/50II, MYNX9500
• SVM series: SVM4100, SVM5100L
• VC series: VC3600, VC430, VC510, VC360030, VC40002SP
• VM series (die & mold): VM5400, VM6500, VM750, VM750L
• VX series (graphite): VX4600C, VX6500C, VX6500G
• XC series (2-spindle): XC4000DA2SP

If your DN Solutions / Doosan mill isn’t listed, we can still help: use the Custom Plate Builder or email your table size and model to dan@tosatool.com.

Add Options & built-to-fit accessories

Select your plate, then Add Options to your Modular Subplate and add built-to-fit hardware accessories. Available add-ons include:

• Keyway locating bores & pins
• Set screws and plugs
• Plate mounting kit (t-nuts and capscrews)
• TT 6″ modular vise
• 8″ modular angle plate
• 20-pc modular pin kit
• Tosa Tool modular full kit or half kit (with shipping)

That way the plate and the accessories that fit it travel together in one order.

Tosa Tool hole pattern (TT)

The TT standard hole pattern is two nestled 1.2500″ grids sharing the same plate:

• Precision bore grid: ø.5010″ ±.0002 TYP on 1.2500″ centers — for locating pins and accurate repeat setups
• Threaded hole grid: 1/2-13 UNC 2B thru TYP on 1.2500″ centers, with ø.5625 × .19 counterbore (~3/16″ deep) — for clamps, bolts, and modular accessories

The two patterns are offset so bores and threaded holes alternate; neighboring holes (bore next to thread) fall on 0.625″ centers. Same pattern across Tosa Tool modular subplates so options and built-to-fit hardware accessories line up from plate to plate.

Material options

• PH — 4140 PreHard steel: excellent strength and durability for production workholding
• MC — medium-carbon steel: strong, long-life steel plate
• AL — 7075-T6 aluminum: light but strong; popular when weight and handling matter

Made to order in Wisconsin

These plates are MTO from TosaTool LLC.

Lead Time: Standard lead time is 6 to 10 weeks, depending on our material suppliers, current workload and the options you select. Need it sooner? Add RUSH service for 15% and we will do our best to get your order out the door as fast as possible, with overtime hours and expedited vendor service.

Complete the setup

After you select your plate, use Add Options to your Modular Subplate for built-to-fit hardware accessories — and check You May Also Like below for the modular vise, angle plates, and clamping kits that finish the TT-pattern setup.

Browse DN Solutions (Doosan) compatible plates · Modular accessories · Custom Plate Builder · FAQ
