Locating pin kit & individual pins for Tosa Tool modular plates — pull-out dowels and screw-in locators, hard and ground to size. Order a kit or buy pins à la carte. Custom pins available on request.
Locating Pins & Locating Pin Kit for CNC Fixtures
Price range: $3.10 through $83.66
Description
Locating pins for TT modular plates
Use these locating pins to register fixtures and workpieces on your Tosa Tool Modular Fixturing Tooling Plate. Hard, ground to size, tight toleranced — enough locating options for the life of the plate.
Kit contents (typical)
- 4× 2″ × .5002″ pull-out dowel pins — min. Rockwell C47, ASME B18.8.2
- 4× 1.2″ × .5002″ pull-out dowel pins — min. Rockwell C47, ASME B18.8.2
- 4× 2″ × .5002″ × .561″ A2 screw-in locator — hardened C55–C60, centerless ground
- 4× 1″ × .5002″ × .561″ A2 screw-in locator — hardened C55–C60, centerless ground
Not sure what you need? Choose the pin kit from the dropdown. Custom pins: email dan@tosatool.com.
Also see pin puller, set screws & plugs, and modular accessories.
Complete the setup
These accessories line up on the Tosa Tool hole pattern. Pair them with OEM modular subplates for your mill, or build any size with the Custom Plate Builder. Questions? Call 608-721-TOOL or email dan@tosatool.com.
