TT6INMV – 6″ Modular Vise

TT6INMV – 6″ Modular Vise

$385.55

8 in stock

(5 customer reviews)

The Tosa Tool 6″ Modular Vise System. A vise that is as big as your modular plate will allow. Easily grip your work piece with our G-NOB .05″ low profile clamping system, use the vise with parallels, or use your existing 6″ Kurt® style vise jaws.  Extremely versatile vise system for all of your modular clamping needs. Not quite as strong as a Kurt Vise, but infinitely more adjustable and capable of over 5000 lfb of clamping force.  Works with all 1.25″ hole pattern modular fixturing tooling plates. ALWAYS IN STOCK, MADE IN USA, SHIPS TODAY WITH STANDARD 2 DAY SHIPPING!

Pat Pend #048124

8 in stock

Description

PRODUCT VIDEO COMING SOON!

When our customers asked us for a low profile vise that worked with our modular designs, we went to work. For many months we considered all of the current vise products out today and also all of the low profile clamping solutions we could find.

Low Profile Clamping was very important, a must to our customers

We also knew that the 6″ Kurt® style Angle Lock is the most widely used milling vise and compatibility with those components was paramount.

Lastly, separate components would allow the vise to become as large as your modular plate giving you unlimited possibilities and VERY strong clamping strength.

This is our Modular Vise: Simple Design, Hardened Tool Steel Components, Ground to Precision Tolerances, Simple To Maintain, Extremely Durable, and Individual Replaceable Grippers all at a Easy To Justify Price.

TT6INMV: 6″ Modular Vise Features:

  • All Tool Steel Construction, Hardened and Precision Ground To Size
  • Simple Sturdy Design Insures Long Fixture Life and Easy Maintenance
  • 1.5″ Jaw Stroke
  • Mount it FAST with our 562 Locating Screws or mount it with .500 dowel pins and cap screws
  • Capable of OVER 5000 LFB of CLAMPING FORCE
  • G-Nob .05″ Low profile Clamping – 4 included
  • HD G-NOB .08″ Low Profile Clamping – 4 optional
  • 1.75″ Height
  • Accepts Standard 6″ Kurt® Style Vise Jaws (use all of your existing jaws, hard and SOFT!)
  • Works With ANY Standard 1.25″ Hole Pattern Fixture Plate
  • Comes Fully Assembled in a heavy duty Storage Box
  • Mounting Hardware, extra G-NOBS and Soft-Jaws all available as options
  • ALWAYS IN STOCK, SHIPS TODAY, MADE IN USA

Additional information

Weight 11.5 lbs
Dimensions 6 × 6 × 1.75 in

5 reviews for TT6INMV – 6″ Modular Vise

  1. Jake M. – CiviL Machine (verified owner)

    I was hesitant at first to invest in a modular vise system but when I got a job with a bunch of 18-24″ long components I went ahead and did it.
    I gotta say, this is a huge game changer and it changes the way I look at setups. The G-Jaw grips are awesome. I have never roughed so much material off hanging on so little stock. I am very pleased with my Tosa Tool setup… it takes a little bit of finesse to get things flat but when you have the process down and you learn to trust it – it’s fantastic.

  2. Steve Rouch – Viking Rails

    These worked out very well for us. We used to do one piece at a time in 2 vises on our VMC4020, now we get 4 on the machine at once and the operator runs another machine as well. Definitely worth every cent to us.

  3. Samual G. – Shop Supervisor (verified owner)

    TOSA TOOL MODULAR VISES FOR THE WIN!! We use these things all over the shop, Often the machinists will just use the movable side as a “Push” for jobs we do on the big mills. At this price point they are VERY useful and cost effective. I was skeptical at first they they would get used, but now we use them all over the shop. Great tool.

  4. Dillon G (verified owner)

    These are really very good, they are NOT a Kurt 6″ vise strong, but they are very capable. Amazing to get a 6″ vise that is AS BIG as the table on my mill, so great all my vise jaws for all my other vises fit. We own 4, looking for 2 more soon.

  5. Noah H. (verified owner)

    The guys in the shop here love these things. We use Saunders fixture plates so we don’t get the pins as far down as we want but these are amazing for what we do anyway. We keep them on the machine all the time and we use them along with clamps for our large panel work. Really adds rigidity and clamping power. Minus 1 star because G-NOBS are weird, but we only used them a few times so far anyway.
